Flared 3026 Aluminum Capillary Tube
Stronger Alloy for Vibration Resistance
Our Flared 3026 Aluminum Capillary Tube uses 3026 aluminum alloy. This alloy is stronger than 3003. It resists vibration and shock very well. It is perfect for mobile AC, vehicle refrigeration, and transport cooling. The flared end is uniform with no cracks. It connects firmly. No leakage. Your system stays reliable on the road.
Wide Temperature Range for Extreme Conditions
This Flared 3026 Aluminum Capillary Tube works from -55°C to +185°C. It handles hot and cold environments. It does not become brittle. It resists aging from refrigerants. The inner wall is smooth. The tolerance is ±0.015mm. Flow is stable. Our factory has 15+ years of experience. We test every tube for flare quality and strength.
Custom Sizes and Fast Delivery
Order this Flared 3026 Aluminum Capillary Tube in outer diameters from 3.0mm to 8.0mm. Inner diameters from 1.0mm to 6.5mm. Wall thickness from 0.5mm to 1.5mm. Available in H14 or O temper. MOQ is 30-400kg. Sample in 48 hours. Delivery in 15-45 days. We support FOB Shanghai/Ningbo. Contact us for a quote.
Product Specifications Table
|
Parameter |
Value / Range |
|
Material |
3026 Aluminum Alloy |
|
Aluminum Content |
≥99.6% |
|
Temper |
H14, O |
|
Tensile Strength |
Rm ≥ 130MPa |
|
Hardness |
HV30~60 |
|
OD Range |
3.0mm ~ 8.0mm |
|
ID Range |
1.0mm ~ 6.5mm |
|
Wall Thickness |
0.5mm ~ 1.5mm |
|
Working Temp |
-55°C ~ +185°C |
|
Applications |
Mobile AC, transport refrigeration |
