Flared TP2 Copper Capillary Tube
Easy Connection with Flared End
Our Flared TP2 Copper Capillary Tube has a standard flared end. This makes connection very easy. You just insert it and tighten the nut. The flare is smooth with no cracks. It seals well and does not leak. It saves you time during installation. This tube is great for air conditioners, refrigerators, and heat pumps.
Soft Temper for Easy Bending and Flaring
This Flared TP2 Copper Capillary Tube is in soft state (O60). It is easy to bend. The flaring process does not cause cracks. The inner wall is smooth. The tolerance is ±0.02mm. Refrigerant flow is stable. Our factory uses high-purity copper with ≥99.9% content. We have 15+ years of experience. Every tube is inspected for flaring quality and size.
Custom Flare Angle and Fast Delivery
You can order this Flared TP2 Copper Capillary Tube with 45° or 90° flare angle. Outer diameter from 1.8mm to 6.35mm. Inner diameter from 0.3mm to 5.0mm. Wall thickness from 0.5mm to 1.3mm. We offer single or double flared ends. MOQ is 50-500kg. Sample in 48 hours. Delivery in 7-15 days for small batches. Pay by T/T or L/C. Get a quote now.
Product Specifications Table
|
Parameter |
Value / Range |
|
Material |
TP2 Copper |
|
Copper Content |
≥99.9% |
|
Temper |
Soft (O60) |
|
Flare Type |
Single / Double end |
|
Flare Angle |
45° / 90° (custom) |
|
OD Range |
1.8mm ~ 6.35mm |
|
ID Range |
0.3mm ~ 5.0mm |
|
Wall Thickness |
0.5mm ~ 1.3mm |
|
Working Temp |
-40°C ~ +150°C |
